With the continuous development of technology, the application prospects of ultra-high frequency ultrasonic cleaning transducers are becoming increasingly broad. In the future, with the continuous progress of materials science and manufacturing technology, the performance of ultra-high frequency ultrasonic cleaning transducers will be further improved, and their application fields will also continue to expand. Meanwhile, with the increasing emphasis on environmental protection and health, ultra-high frequency ultrasonic cleaning technology, as an environmentally friendly and healthy cleaning method, will be widely applied in various fields.
As an efficient and environmentally friendly cleaning method, ultra-high frequency ultrasonic cleaning transducers have broad application prospects and development space. In the future, with the continuous progress of technology and the expansion of application fields, ultra-high frequency ultrasonic cleaning transducers will play an increasingly important role in various fields.
Type | Length(mm) | Weight(g) | Frequency(KHz) | Resonance Impedance (Ω) |
Static Capacity (pF)±10% |
Input Power(W) |
PU-UT-5435 PZT-4 |
36 | 135 | 54 | 10-20 | 3200 | 35 |
PU-UT-6860 PZT-8 |
80 | 460 | 68 | 10-20 | 3800 | 60 |
PU-UT-68120 PZT-4 |
67 | 588 | 68 | 10-20 | 7800 | 120 |
PU-UT-8060 PZT-4 |
60 | 325 | 80 | 10-20 | 5400 | 60 |
PU-UT-12060 PZT-4 |
56 | 260 | 120 | 10-20 | 5400 | 60 |
PU-UT-13550 PZT-4 |
54 | 215 | 135 | 10-20 | 4200 | 50 |
