The ultrasonic pulse generator power supply is a high-power pulse ultrasonic generator, in which a microcontroller generates a control signal and drives the entire bridge through a bridge drive circuit to achieve the purpose of controlling capacitor charging and discharging, thereby controlling the pulse excitation circuit to output the required pulse width of the double pulse signal. Finally, the pulse amplitude is greatly increased through a double pulse transformer
|
Type |
Power（W） |
Frequency (KHz) |
Transducer numbers |
Size |
|
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE |
||||
|
PU-GT300 |
300W |
20khz,25khz,28khz,33khz,40khz |
3-6 |
300x360x150 |
|
PU-GT600 |
600W |
20khz,25khz,28khz,33khz,40khz |
6-12 |
300x360x150 |
|
PU-GT900 |
900W |
20khz,25khz,28khz,33khz,40khz |
9-18 |
300x360x150 |
|
PU-GT1000 |
1000W |
20khz,25khz,28khz,33khz,40khz |
10-20 |
300x360x150 |
|
PU-GT1200 |
1200W |
20khz,25khz,28khz,33khz,40khz |
12-24 |
300x360x150 |
|
PU-GT1500 |
1500W |
20khz,25khz,28khz,33khz,40khz |
15-30 |
300x360x150 |
|
PU-GT1800 |
1800W |
20khz,25khz,28khz,33khz,40khz |
18-36 |
300x360x150 |
|
PU-GT2000 |
2000W |
20khz,25khz,28khz,33khz,40khz |
20-40 |
300x360x150 |
|
PU-GT2400 |
2400W |
20khz,25khz,28khz,33khz,40khz |
24-48 |
300x360x150 |
|
PU-GT3000 |
3000W |
20khz,25khz,28khz,33khz,40khz |
50-60 |
300x360x150 |
|
High Frequency |
300W-1200W |
65-80khz |
||
|
High Frequency |
300W-1200W |
120-135khz |
||
